B&M supercharger (Page 6/6)
Will OCT 14, 10:43 AM

quote
Originally posted by Coolkoolpyle:

That's why I machine .080 off the outside of a SBC rod and use arp rod bolts

Same in every other way other than the needed removal of the side material and pressing in a nice bushing so the wrist pin floats in the small end of the rod..

Modify a SBC main girdle (just cut off the front section and the rest fits like it was designed for the 60degree engines)
and use some arp studs and you got a bottom end that will take 350+ hp all day long.



How do you narrow the SBC rods? I've seen it done by ID chucking the big end in a lathe, but always curious about other ideas.

Interesting tidbit about the SBC main girdle. It's pretty wild that the two engines use the same main bolt pattern.



quote
Originally posted by Coolkoolpyle:

Machine the heads to take SBC screw in studs
Use SBF 1.6 roller rockers and SBC valves and you got a fierce top end to match.




Another interesting tidbit. I'd heard about screw in rocker studs, but not SBF rockers.


quote
Originally posted by Coolkoolpyle:

I'm a pretty busy guy but maybe over the winter I'll find the time to show the 60degree guys the tricks to power and long life.
(there are a couple of oiling system mods that are game changers in the bottom end)
Especially the 2.8.

Maybe I should do one of those "how to Hotrod the 60* V6"
books you see on the more popular engines.

In any case I'm excited to get started

More than anything
I really enjoy projects like this.



I'm curious about the oiling modification.

Maybe you should publish a book.

I live for building, and what's important is that you build what you like.


quote
Originally posted by fierosound:

GM's Chevy Power Manual when engine came out.
http://fieroinfo.com/manual...0V6_Power_Manual.pdf




I might even have one around, but the magic of modern technology makes that superfluous.

[This message has been edited by Will (edited 10-14-2020).]

Blacktree OCT 14, 11:20 AM
ARP makes rocker studs for conversion to SBC rockers. Then you can use narrow-body SBC rockers in your V6. It's a common mod, and fairly inexpensive. With the conversion studs, and some aftermarket springs and retainers, my 3.4 V6 valvetrain can handle up to .550" valve lift. No head machining necessary. It uses the same heads as the 2.8 V6.

https://www.summitracing.com/parts/arp-100-7201
fierosound OCT 14, 12:11 PM

quote
Originally posted by fierosound:

GM's Chevy Power Manual when engine came out.
http://fieroinfo.com/manual...0V6_Power_Manual.pdf




quote
Originally posted by Will:

I might even have one around, but the magic of modern technology makes that superfluous.



Putting SBC rods and valves in is nothing new and was covered in that book plus other guides.
But I agree that things like roller rockers and EFI etc. have made some progress.

[This message has been edited by fierosound (edited 10-14-2020).]

jdv NOV 19, 05:56 PM
Bump for boost
