With the increased length of the car, it almost seams to be begging for Fender flares for the back and possibly the front. i can imagine them on your car, but dont have the photoshop savy to mock it up. have you thought about flares and wider wheelsbase?
with the rear suspension up grade i have planned i may just have to fair the rear .I am in the process of fabbing up a tube cradle for use with vette rear upper and lower control arms and uprights
[This message has been edited by bubbajoexxx (edited 12-01-2004).]
time to up the anti again as I have started to build the tube cradle for the vette suspension here are some start pics asyou can see the attaching points for the a arms fully encircle the frame tubes for max strenght, not gut welded on as in this pic you would have to sever a tube completely to brake one of my brackets of these are the uprights that bolt to the lower controll arms this is a un equal length A arm setup short uppers long lowers
------------------
[This message has been edited by bubbajoexxx (edited 12-03-2004).]
Very cool. I thought about something like that but quickly shoved it to the back of my mind with my plans for casting my own engine etc. Way to go for actually DOing all of this.
------------------ Alan Frazier '88 coupe auto 74k miles for sale '86 GT-'92 3.4 TDC 5 speed(sold) '84 2m4 daily driver
What size is that tube? Wall thickness? Are you going to bend it? If so, how? This is turning out to be one heck of a project. Where in Canada are you at? I gotta come see this thing when it's done!! Very amazing work.
shop_rat45 1 3/4 by .125 wall the front tube will be curved at each end where it goes into the body mount and cross braced at the suspension points the rear will curve up to the frame then braced back to the center of the a arm attaching points with 1 1/4 inch .125 wall tubing
shop_rat45 1 3/4 by .125 wall the front tube will be curved at each end where it goes into the body mount and cross braced at the suspension points the rear will curve up to the frame then braced back to the center of the a arm attaching points with 1 1/4 inch .125 wall tubing
Toronto
What are you going to use to bend it? Some sort of tube bender? That's the size I want to use for my control arms, but I'm still debating on how to bend them. Also, where are you getting the tube from? Locally? Thanks.
shop_rat45 the tubing I get from the Metal Super Market here in Toronto and I have control arm tubing and it is not regular tubing it is a special steel alloy that will resist twisting and I have access to a pipe bender from the Guy,s at RIO automotive and welding here in TO but you can buy pipe benders cheep from Princes Auto in Canada 149 .00 dollars CD from there web site when on sale . I will post a pic of the steel for control arms tomorrow .
What a work of art. Kit car, but custom. Still retains the Fiero poise. Beautiful work. Is that a C5 suspension or C6? The longer wheel base will really help at high speeds. I probably missed it, but how much HP is that motor putting out? (did I read that it was a N*?)
wow.
------------------ Paul 2003 Tube Chassis IMSA Race Car - 3.8 lb./hp | 1987 Fiero GT 119,xxx, 3.1 motor, 1 1/4" rear swaybar, Full poly
you did all that to an indy?!? i mean, i like it, dont get me wrong, but an indy!
------------------ 1985 Pontiac Fiero 2.5 SE, 220,000 currently going under the knife to become a chopped hard top custom convertible, watch for the build up thread more pics of my 85 can be found here 1987 Pontiac Fiero GT, 141,500 miles!decklid window, silver guages. 1987 Pontiac Fiero 2.8 SE, 54,000 miles :( DOOMED, im cutting her up for scrap metal very soon! RIP
Have you ever imagined a world with no hypothetical situations?
tednelson83 yes 100% indy but was so bad it was not worth it to simply restore the car and indys with that kind or rust damage are worth nothing when most of the original parts are missing this car was hacked up bad and I dont like scraping Fieros when I still have some hope for them Steve Rossi,s car was just as bad when I rebuilt his to put the 4.9 in it .Most Indy,s in the shape this one was in became parts cars but not this one.
you did all that to an indy?!? i mean, i like it, dont get me wrong, but an indy!
Settle down it's not like an Indy is going to be worth anything anyway. If your lucky in another 20 years it might double it's original Retail sale value if you have one that's in perfect condition.
Back on topic, like the hidden LCD in the dash good idea.
Settle down it's not like an Indy is going to be worth anything anyway. If your lucky in another 20 years it might double it's original Retail sale value if you have one that's in perfect condition.
Back on topic, like the hidden LCD in the dash good idea.
The Indy Cars will always be worth good money as there is always a buyer who is willing to pay for a good car in excellent condition and there are quit a few out there I have seen one go for 19,000 US with 17 miles on it and the buyer did not even drive it home he had it trailered so as to keep the milage as close to what it is now and there is another one here in Canada with 6 miles on it and the owner has never driven the car but he also has 5 other pace car replicas from GM in the same condition as he buy,s them for there future value not to drive. The cars he purchased where never driven they came off the trailer right into the warehouse as aranged with the dealer he ordered them from and have never been titled he only has the original bill of sale .They are still know as new cars untill titled .
its funny how even on page 24 you have pff regulars coming on this thread and saying how they just found it and cant believe it.i think it took me 8 pages to finally find the thread. its been great ever since.
its funny how even on page 24 you have pff regulars coming on this thread and saying how they just found it and cant believe it.i think it took me 8 pages to finally find the thread. its been great ever since.
its funny how even on page 24 you have pff regulars coming on this thread and saying how they just found it and cant believe it.i think it took me 8 pages to finally find the thread. its been great ever since.
I never loose it its one of my favorites, page one every time.
WOW nice May I sugest you put a frame mount from the cradle to the space frame at or near the front A arm mount. The cradle is kind of long and seems like it would be a good idea to make it a structural member by adding a few more mounting points. The stock Fiero cradle mounting points are weak. But I am sure you fixed that.
This is way kool But have you had it running yet ?? And what do you plan to do with the car Drag it ?? i dont think even with the corvett lower control arms, It wont handle its to long and has a fat Ass
Way to go for actually DOing all of this.
you did all that to an indy?!?
